Eppendorf Cryocube F101h with Chart Recorder and CO2 Backup

Code: fre6025 24

The Eppendorf CryoCube F101h ultra-low temperature (ULT) freezer combines compact design with real -80°C to offer long-lasting and reliable ULT technology for safe sample storage. By taking ad...


read more

Your Price
£12,600.00 EACH
£15,120.00 inc. VAT

5 Year Warranty
Service Centre
Calibration Service

The Eppendorf CryoCube F101h ultra-low temperature (ULT) freezer combines compact design with real -80°C to offer long-lasting and reliable ULT technology for safe sample storage. By taking advantage of ultra-efficient, compact vacuum insulation panels which are used in combination with traditional PU foam insulation, slimming down the freezer wall thickness from 130 to 80mm. This gives a small footprint, limited to half a square meter, perfect for small labs, while still having space for up to 6000 vessels (1.5mL).

  • Inner doors are gasketed as well as insulated creating 2 separate compartments minimizing cold air loss while you access your samples
  • Easy-to-read LED control panel and alarm status
  • Special vacuum vent with plunger ergonomically located to gain immediate access to your freezer
  • Inner doors can be quickly removed without the need for tools for easier and faster defrosting
  • Full stainless steel interior for easy cleaning during maintenance and defrost cycles; powder-coated steel exterior
  • Special low-temperature outer door seals allow gaskets to remain flexible at -86°C and prevent ice buildup for easy access to samples
  • Password protection of alarm and temperature setpoints to prevent unauthorized setting changes

Cooling liquidR290 / R170
Cooling typeAir-cooled
Heat output263 W
InsulationVacuum insulation paneling / polyurethane foam
Capacity101L
No. of internal doors2
No. of compartments2
Max. racks per freezer6
DisplayClassic
Noise level55
High-efficiencyYes
Power supply230 V, 50 Hz
Max. power consumption6300 W
Footprint (WxD)90 x 56.6 cm
Weight w/o accessories123 kg / 271 lb
Temperature range-50°C to -86°C
Access port2
Pull-down time to -80°C2 h 20 min*
Box capacity per freezer
53mm (2in) tall boxes60
64mm (2.5in) tall boxes48
76mm (3in) tall boxes36
89mm (3.5in) tall boxes24
102mm (4in) tall boxes24
127mm (5in) tall boxes24
Box capacity per rack
53mm (2in) tall boxes10
64mm (2.5in) tall boxes8
76mm (3in) tall boxes6
89mm (3.5in) tall boxes4
102mm (4in) tall boxes4
127mm (5in) tall boxes4
*Empty freezer with shelves fitted, upright freezers only, pull down from 21 – 23°C ambient conditions
Code
Description
Unit Size
List Price
Qty
FRE6024
Unit:EACH
List Price: £9,382.00
Source:List Price
Discontinued
Code
Description
Unit Size
List Price
Qty
FRE6168
Unit:EACH
List Price: £88.00
Source:List Price
ADD
Capacity, L101
Dims, w x d x h, mm900 x 566 x 830
Temp Range, °C-50 to -86
TypeUpright
Weight, kg123
This product has met the following criteria:
